Pro Series Sw Mech 10A 4Pos OFF-1-2-3

Ideal Part Number PDLP387M4R3 Manufacturer Number PDLP387M4R3-XW Barcode 9416175263927

Product Details

PDL Pro Series Switch Mechanism 10 Amp 4 Position OFF-1-2-3

Switch mechanism with rotary knob. Switch has 4 positions: Off, 1, 2, 3. 300 Series mechanism. Suitable for PDL Pro Series, Iconic, Iconic Styl and Iconic Essence. Rated current: 10A. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Nominal voltage
230
Mounting method
Module Frame
Assembly arrangement
Basic Element
Method of operation
Rotary
Connection type
Screw terminal
Rated current
10
Suitable for degree of protection (IP)
IP20
Number of modules (module system)
1
Nominal voltage (unit)
V
Rated current (unit)
A
