DIN-T RCBO 3P+N 63A 10kA D-Curve 300mA Type A Longbody 54mm

DIN-T RCBO 3P+N 63A 10kA D-Curve 300mA Type A Longbody 54mm

by NHP Electrical Engineering Products
Ideal Part Number NHPDTRT63300AD Manufacturer Number DTRT63300AD Barcode 9321807008169

Product Details

DIN-T RCBO 3P+N 63A 10kA D-Curve 300mA Type A Longbody 54mm
Request a quote for this product

Enter details to request a quote

Technical Specifications

Voltage type
AC
Rated current
63
Rated voltage
415
Rated insulation voltage Ui
500
Leakage current type
A
Width in number of modular spacings
3
Degree of protection (IP)
IP40
Connectable conductor cross section solid-core
1,25
Connectable conductor cross section multi-wired
1,16
Number of poles (total)
4
Rated impulse withstand voltage Uimp
4
Disconnection characteristic
Undelayed
Rated short-circuit breaking capacity according to EN 61009
10
Rated voltage (unit)
V
Rated insulation voltage Ui (unit)
V
Connectable conductor cross section solid-core (unit)
mm²
Connectable conductor cross section multi-wired (unit)
mm²
Rated impulse withstand voltage Uimp (unit)
kA
