Cable 1.84mm 2c Flex Marine Black
Firstflex Cables

Cable 1.84mm 2c Flex Marine Black

Ideal part number AFLMFE226030RB Manufacturer number MFE226030R/B Barcode 9416024115452
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Cable 1.84mm 2 core Flex Marine Black

Technical specifications

Colour
Red
Total no. of cores
2
No. of cores excl. earth
2
No. of earth
0
Nominal size
1.84 mm²
Approximate stranding No. of wires x mm
26/0.3
Approximate overall diameter
2.80 x 5
Rated voltage
50VAC / 120VDC
Approx weight per km
43 kg
Relevant standards
AS/NZS 1125, IEC 60332-1
Cable class
5
Conductor type
Tinned copper
Insulation
SPVC
Material
PVC
Bedding sheath
false
Inner sheath
false
Armoured
false
Screened
false
Laying up
false
Separator
false
Filler
false
Maximum conductor temperature
90°C
Minimum operating temperature
-20°C
Maximum operating temperature
90°C
Minimum operating temperature flexing
-5°C
Maximum operating temperature flexing
75°C
