Marine Flex 0.56mm 2c 90Deg Black (EZ Strip)
Firstflex Cables

Marine Flex 0.56mm 2c 90Deg Black (EZ Strip)

Ideal part number AFLMTS27032BEZ Manufacturer number MTS27032BEZ Barcode 9416024118293
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Marine Flex 0.56mm 2 Core 90Deg Bl ACk (EZ Strip) AC 50v / DC 120V

Technical specifications

Colour
Black
Core colour
Black, Red
Total no. of cores
2
No. of cores excl. earth
2
No. of earth
0
Nominal size
0.56 mm²
Approximate stranding No. of wires x mm
7/0.32
Approximate overall diameter
3.20 x 5
Rated voltage
50VAC / 120VDC
Approx weight per km
27 kg
Relevant standards
AS/NZS 1125, IEC 60332-1
Cable class
5
Conductor type
Tinned copper
Insulation
SPVC
Sheath
SPVC
Material
PVC
Bedding sheath
false
Inner sheath
false
Armoured
false
Screened
false
Laying up
false
Separator
false
Filler
false
Maximum conductor temperature
90°C
Minimum operating temperature
-20°C
Maximum operating temperature
90°C
Minimum operating temperature flexing
-5°C
Maximum operating temperature flexing
75°C
