Terminal Blocks 10mm Black (30A 400V)

Terminal Blocks 10mm Black (30A 400V)

by BizLine
Ideal Part Number BIZ320003 Manufacturer Number BIZ 320003 Barcode 3700420310709

Product Details

Terminal Strip Connector Block 12-Way 10mm Black (30A 400V)

These 12-way ultra flexible terminal blocks can be separated in 1.5 turns without the use of tools.

Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Mounting method
Other
Colour
Black
Rated voltage
400 V
Number of poles
12
Operating temperature
-25-40 °C
Number of clamp positions per pole
2
Closing plate required
no
Type of electrical connection 1
Screw connection
Type of electrical connection 2
Screw connection
Drill hole distance centrically
11 mm
Transparent
no
Connectable conductor cross section solid-core
0-6 mm²
Connectable conductor cross section fine-strand with cable end sleeve
0-6 mm²
Connectable conductor cross section fine-strand without cable end sleeve
0-10 mm²
Connectable conductor cross section multi-wired
0-10 mm²
Material insulation body
Thermoplastic
Rated current In
57 A
Explosion-tested version 'Ex e'
no
Country of Origin
China
