MCB 63A 1P 10KA C Curve
Eaton

MCB 63A 1P 10KA C Curve

Ideal part number EATPLSMC63MW Manufacturer number PLSM-C63-MW
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Miniature Circuit Breaker 63Amp 1Pole 10KA C Curve

Eaton Moeller series xPole - PLS6/M MCB. PLSM, 1-pole, tripping characteristic: C, rated current In: 63 A, rated switching capacity IEC/EN 60898-1: 10 kA

Technical specifications

Voltage type
AC
Built-in depth
70.5 mm
Rated current
63 A
Rated voltage
230 V
Frequency
50-60 Hz
Release characteristic
C
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
1
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
1
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles
1 (Total: 1)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10 kA
