MCB 10A 3P 10KA D Curve
Eaton

MCB 10A 3P 10KA D Curve

Ideal part number EATPLSMD103MW Manufacturer number PLSM-D10/3-MW
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Miniature Circuit Breaker 10Amp 3Pole 10KA D Curve

Eaton Moeller series xPole - PLS6/M MCB. PLSM, 3-pole, tripping characteristic: D, rated current In: 10 A, rated switching capacity IEC/EN 60898-1: 10 kA

Technical specifications

Voltage type
AC
Built-in depth
70.5 mm
Rated current
10 A
Rated voltage
400 V
Frequency
50-60 Hz
Release characteristic
D
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
3
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
3
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles
3 (Total: 3)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10 kA
