MCB 10A 1P 10KA D Curve

MCB 10A 1P 10KA D Curve

by Eaton
Ideal Part Number EATPLSMD10MW Manufacturer Number PLSM-D10-MW

Product Details

Miniature Circuit Breaker 10Amp 1Pole 10KA D Curve
Request a quote for this product

Enter details to request a quote

Technical Specifications

Voltage type
AC
Built-in depth
70
Rated current
10
Rated voltage
230
Frequency
50-60
Release characteristic
D
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
1
Degree of protection (IP)
IP20
Number of protected poles
1
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles (total)
1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10
Built-in depth (unit)
mm
Rated current (unit)
A
Rated voltage (unit)
V
Frequency (unit)
Hz
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V (unit)
kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V (unit)
kA
