MCB 40A 1P 10KA D Curve

MCB 40A 1P 10KA D Curve

by Eaton
Ideal Part Number EATPLSMD40MW Manufacturer Number PLSM-D40-MW

Product Details

Miniature Circuit Breaker 40Amp 1Pole 10KA D Curve
Request a quote for this product

Enter details to request a quote

Technical Specifications

Voltage type
AC
Built-in depth
70 mm
Rated current
40 A
Rated voltage
230 V
Frequency
50-60 Hz
Release characteristic
D
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
1
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
1
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles
1 (Total: 1)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10 kA
