RCBO 1P+N 32A 6kA C-Curve 30mA Type A 2Mod
Hager

RCBO 1P+N 32A 6kA C-Curve 30mA Type A 2Mod

Ideal part number HAGADA932T Manufacturer number ADA932T Barcode 3250611011637
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

RCBO 2 Module Type A 1P+N 32A 6kA C-Curve 30mA

AxA9xxT RCBO are two module wide, making them ideal for retrofit in installations where space is limited. Available as ‘C’ curve in various current ratings from 6A - 40A. Available in 30 and 100mA. Can can be used in DIN rail enclosures and the invicta panelboard range.

Technical specifications

Voltage type
AC
Built-in depth
68 mm
Rated current
32 A
Rated voltage
240 V
Release characteristic
C
Rated fault current
0.03 A
Leakage current type
A
Surge current capacity
0.25 kA
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
2
Frequency
50 Hz
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
1
Concurrently switching neutral conductor
yes
Rated short-circuit breaking capacity according to IEC 60947-2
6 kA
Number of poles
2 (Total: 2)
Anti-nuisance tripping version
no
