RCBO Single Mod 6A Type A 1P 6kA 30mA C-Curve
Hager

RCBO Single Mod 6A Type A 1P 6kA 30mA C-Curve

Ideal part number HAGADC906T Manufacturer number ADC906T Barcode 3250611033325
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

RCBO One Module 1P+N 6A Type A 1P 6kA 30mA C-Curve

Hager's residential range of 'onekombo' single module electronic residual current circuit breakers with overcurrent protection (RCBOs) leads to safety and simplicity; it offers a breaking capacity of 6kA and can be completely integrated with other Hager modular devices. Particularly compact, the 'onekombo' is only one module wide making it ideal for retrofit installations where space is limited, allowing a greater number of RCBOs to be installed in the one enclosure. To assist in the prevention of nuisance tripping, the type 'A' onekombo gives the added safeguard against 'pulsating DC components' that can be generated from modern appliances such as washing machines, LCD TVs, computers etc.

Technical specifications

Voltage type
AC
Built-in depth
70 mm
Rated current
6 A
Rated voltage
240 V
Release characteristic
C
Rated fault current
0.03 A
Leakage current type
A
Surge current capacity
0.25 kA
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
1
Frequency
50 Hz
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
1
Concurrently switching neutral conductor
yes
Rated short-circuit breaking capacity according to IEC 60947-2
10 kA
Number of poles
2 (Total: 2)
Anti-nuisance tripping version
no
