MCB 2P 32A 6kA 2mod D-Curve Residential
Hager

MCB 2P 32A 6kA 2mod D-Curve Residential

Ideal part number HAGMDN232P Manufacturer number MDN232P Barcode 3250614353147
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

MCB 2P 32A 6kA 2 Module D-Curve Residential

The protection and control of circuits against overloads and short-circuits in residential installations. Tripping curve - D magnetic setting between 10 and 20In. To AS/NZS 60898. Not For Use on DC

Technical specifications

Voltage type
AC
Built-in depth
70 mm
Rated current
32 A
Rated voltage
415 V
Frequency
50 Hz
Release characteristic
D
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
2
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
2
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles
2 (Total: 2)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
6 kA
