MCB 1P 10A 6kA C-Curve

MCB 1P 10A 6kA C-Curve

by Hager
Ideal Part Number HAGMSN110 Manufacturer Number MSN110 Barcode 3250614323942

Product Details

MCB 1P 10A 6kA C-Curve Connection Capacity: 25mm2 rigid, 16mm2 flexible. AS/NZS 60898

Hager's range of MSN MCB's are intended for use within residential intallations. This range of MCBs offer new features, better connection, superior performance and increased levels of security. This range and its multiple innovations including Bi-connect, allowing two connection points
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Voltage type
AC
Built-in depth
70
Rated current
10
Rated voltage
240
Frequency
50
Release characteristic
C
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
1
Degree of protection (IP)
IP20
Number of protected poles
1
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles (total)
1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
6
Built-in depth (unit)
mm
Rated current (unit)
A
Rated voltage (unit)
V
Frequency (unit)
Hz
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V (unit)
kA
