MCB 3P 63A 10kA C-Curve

by Hager

Product Details

MCB 3P 63A 10kA C-Curve Connection Capacity: 25mm2 rigid, 16mm2 flexible. AS/NZS 60898

Hager's range of NT MCB's are intended for use within commercial and light industrial premises. This range of MCBs offer new features, better connection, superior performance and increased levels of security. This range and its multiple innovations delivers more performance,more features, more connection facilities and more security
Request a quote for this product

Enter details to request a quote

Technical Specifications

Voltage type
AC
Built-in depth
70 mm
Rated current
63 A
Rated voltage
415 V
Frequency
60 Hz
Release characteristic
C
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
3
Degree of protection
IP20 (Ip: IP20)
Number of protected poles
3
Concurrently switching neutral conductor
no
Additional equipment possible
yes
Number of poles
3 (Total: 3)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10 kA
