Main Switch 2P 80A Red Toggle
Hager

Main Switch 2P 80A Red Toggle

Ideal part number HAGSBR280 Manufacturer number SBR280 Barcode 3250615510433
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Main Switch 2 Pole 80 Amp Red Toggle

For use as a switch isolator in all types of circuits. As defined in AS/NZS3000-2018, clause 2.3.3. “The supply to every installation shall be controlled by a main switch or switches that control the whole installation”. Positive contact indication, with ON position ‘I’ in red and OFF position ‘O’ in green. AC 22B duty specification (mixed resistive and inductiveloads. Not motors) PZ2 terminal screw for all ratings. Bi-connect terminals

Technical specifications

Voltage type
AC
Switching function
Isolation Switch
Built-in depth
68 mm
Rated current
80 A
Rated voltage
400 V
Number of poles
2
Short-circuit breaking capacity
0.96 kA (Icw: 0.96)
Rated switching capacity
1.354 kA
Width in number of modular spacings
2
Colour calotte
Red
Min. rated voltage
400 V
Degree of protection
IP20 (Ip: IP20)
