DIN-T MCB 1P 20A 6kA D-Curve

DIN-T MCB 1P 20A 6kA D-Curve

by NHP Electrical Engineering Products
Ideal Part Number NHPDTM6120D Manufacturer Number DTM6120D Barcode 4053546126563

Product Details

DIN-T Miniature Circuit Breaker 1P 20A 6kA D-Curve
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Voltage type
DC
Rated current
20
Rated voltage
240 V
Frequency
50,60 Hz
Release characteristic
D
Rated insulation voltage Ui
440 V
Pollution degree
3
Width in number of modular spacings
1
Degree of protection
IP40 (Ip: IP40)
Number of protected poles
1
Connectable conductor cross section solid-core
0.75,35 mm²
Connectable conductor cross section multi-wired
0.75,35 mm²
Ambient temperature during operating
-25,55 °C
Number of poles
1 (Total: 1)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
6 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
10 kA
Rated impulse withstand voltage Uimp
4 kA
