DIN-T RCCB 1P+N 40A 30mA Type A 36mm

DIN-T RCCB 1P+N 40A 30mA Type A 36mm

by NHP Electrical Engineering Products
Ideal Part Number NHPDTRCD24030A Manufacturer Number DTRCD24030A Barcode 8012542641155

Product Details

DIN-T RCCB 1P+N 40A 30mA Type A 36mm
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Mounting method
DIN rail
Voltage type
AC
Rated current
63
Rated voltage
240 V
Rated insulation voltage Ui
500 V
Number of poles
2
Leakage current type
Other
Pollution degree
2
Width in number of modular spacings
2
Degree of protection
IP40 (Ip: IP40)
Connectable conductor cross section solid-core
1,25 mm²
Connectable conductor cross section multi-wired
1,16 mm²
Ambient temperature during operating
-25,70 °C
Rated impulse withstand voltage Uimp
4 kA
