DIN-T RCCB 3P+N 63A 100mA Type A 72mm

DIN-T RCCB 3P+N 63A 100mA Type A 72mm

by NHP Electrical Engineering Products
Ideal Part Number NHPDTRCD463100A Manufacturer Number DTRCD463100A Barcode 8012542643555

Product Details

DIN-T RCCB 3P+N 63A 100mA Type A 72mm
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Mounting method
DIN rail
Voltage type
AC
Rated current
63
Rated voltage
415 V
Rated insulation voltage Ui
500 V
Number of poles
4
Leakage current type
A
Pollution degree
2
Width in number of modular spacings
4
Degree of protection
IP40 (Ip: IP40)
Connectable conductor cross section solid-core
1,25 mm²
Connectable conductor cross section multi-wired
1,16 mm²
Ambient temperature during operating
-25,70 °C
Rated impulse withstand voltage Uimp
4 kA
