DIN-T RCBO 1P+N 10A 10kA C-Curve 100mA Type A 36mm

DIN-T RCBO 1P+N 10A 10kA C-Curve 100mA Type A 36mm

by NHP Electrical Engineering Products
Ideal Part Number NHPDTRD10100A Manufacturer Number DTRD10100A Barcode 8012542684053

Product Details

DIN-T RCBO 1P+N 10A 10kA C-Curve 100mA Type A 36mm
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Voltage type
AC
Rated current
10
Rated voltage
240 V
Rated insulation voltage Ui
500 V
Leakage current type
A
Width in number of modular spacings
2
Degree of protection
IP40 (Ip: IP40)
Connectable conductor cross section solid-core
1,35 mm²
Connectable conductor cross section multi-wired
1,35 mm²
Number of poles
2 (Total: 2)
Rated impulse withstand voltage Uimp
4 kA
Disconnection characteristic
Undelayed
Rated short-circuit breaking capacity according to EN 61009
10
