DIN-T RCBO 3P+N 50A 10kA C-Curve 30mA Type A Longbody 54mm
NHP Electrical Engineering Products

DIN-T RCBO 3P+N 50A 10kA C-Curve 30mA Type A Longbody 54mm

Ideal part number NHPDTRT5030A Manufacturer number DTRT5030A Barcode 9321807006462
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

DIN-T RCBO 3P+N 50A 10kA C-Curve 30mA Type A Longbody 54mm

Technical specifications

Voltage type
AC
Rated current
50
Rated voltage
415 V
Rated insulation voltage Ui
500 V
Leakage current type
A
Width in number of modular spacings
3
Degree of protection
IP40 (Ip: IP40)
Connectable conductor cross section solid-core
1,25 mm²
Connectable conductor cross section multi-wired
1,16 mm²
Number of poles
4 (Total: 4)
Rated impulse withstand voltage Uimp
4 kA
Disconnection characteristic
Undelayed
Rated short-circuit breaking capacity according to EN 61009
10
