Switch 2Gang 50A 3P 500V IP66 Grey

Product Details

PDL 56 Series Switch Isolation 50A 3 Pole 500V 2 Gang IP66 Grey

All of the 56 Series extensive range of 415V Switches are fully motor rated to AC23A and AC3, making them suitable for switching the harshest loads likely to be found in industry.
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Nominal voltage
500 V
Mounting method
Surface mounted
Assembly arrangement
Switch Less enclosure
Method of operation
Rotary
Colour
Grey
Connection type
Screw Terminal
Rated current
50 A
Material quality
Polycarbonate (PC)
Material
Plastic
Type of fastening
Screw mounting
RAL-number
7035 (Similar: 7035)
Push button switch
no
Surface finishing
Gloss
Suitable for degree of protection
IP66 (Ip: IP66)
Device width
95 mm
Device height
190 mm
Device depth
66 mm
Label space/information surface
without labelling field
Number of modules
2 (Module system: 2)
