Comb Busbar 1L + N 80A 24 Module Top Feed
Schneider Electric

Comb Busbar 1L + N 80A 24 Module Top Feed

Ideal part number SCHA9XPC624 Manufacturer number A9XPC624 Barcode 3606489443566
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Acti9 Comb Busbar 1L+N 9mm pitch 24 modules 80A

This Acti9 product is a cuttable horizontal comb busbar for Acti9 iC40. It is dedicated to (Neutral, Line) installations. The distribution type is (N, L1). It is a set of 1 product. It is suitable for 24 devices with 1P+N pole and without associated auxiliaries. The length is 434mm. The total number of modules of 18mm is 24. The Ie rated operational current at 40°C is 80A. The Ui rated insulation voltage is 400VAC. The Ue rated operational voltage is 230VAC. The colour of the device is white (RAL 9003). The pollution degree is 3. The degree of protection is IP20 with end-pieces and tooth covers. According to IEC 60695-2-1 standard, the fire resistance is self-extinguishing at 960°C within 30s. It complies with IEC 61439-1 standards.

Technical specifications

Insulated
yes
Number of phases
1
Rated permanent current Iu
80 A
Number of poles
2
Length
487 mm
Type of electric connection
Pin
Suitable for devices with auxiliary switch
no
Suitable for devices with N-conductor
yes
Suitable for number of devices
24
Max. rated operation voltage Ue
230 V
Module width
9 mm
