NSX100 Trip Unit 3P Magnetic 12.5A MA12.5
Schneider Electric

NSX100 Trip Unit 3P Magnetic 12.5A MA12.5

Ideal part number SCHC103MA013 Manufacturer number C103MA013 Barcode 3606482000322
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100 Trip Unit, 3 poles Magnetic 12.5A MA12.5

This MA12.5 is a 3 poles 3d magnetic trip unit used on ComPacT NSX 100 circuit breakers. This 12.5A rating magnetic trip unit is an optimum choice for motor protection applications. It embeds an adjustable instantaneous magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
12.5 A
Number of poles
3
Short-circuit release function
Undelayed
