NSX100/160 Trip Unit 3P Magnetic 25A MA25
Schneider Electric

NSX100/160 Trip Unit 3P Magnetic 25A MA25

Ideal part number SCHC103MA025 Manufacturer number C103MA025 Barcode 3606482000339
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100/160 Trip Unit, 3 poles Magnetic 25A MA25

This MA25 is a 3 poles 3d magnetic trip unit used on ComPacT NSX 100/160 circuit breakers. This 25A rating magnetic trip unit is an optimum choice for motor protection applications. It embeds an adjustable instantaneous magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
25 A
Number of poles
3
Short-circuit release function
Undelayed
