NSX100/160/250 Trip Unit 3P 3D Magnetic 100A MA100
Schneider Electric

NSX100/160/250 Trip Unit 3P 3D Magnetic 100A MA100

Ideal part number SCHC103MA100 Manufacturer number C103MA100 Barcode 3606482000353
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100/160/250 Trip Unit, 3 poles 3D Magnetic 100A MA100

This MA100 is a 3 poles 3d magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating magnetic trip unit is an optimum choice for motor protection applications. It embeds an adjustable instantaneous magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
100 A
Number of poles
3
Short-circuit release function
Undelayed
