NSX100 Trip Unit 3P 3D 16A Thermal-Magnetic TM16G
Schneider Electric

NSX100 Trip Unit 3P 3D 16A Thermal-Magnetic TM16G

Ideal part number SCHC103MG016 Manufacturer number C103MG016 Barcode 3606482000483
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100 Trip Unit, 3 poles 3D 16A Thermal-Magnetic TM16G

This TM16G is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100 circuit breakers. This 16A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
16 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
11.2…16 A
