NSX100 Trip Unit 3P 3D 25A Thermal-Magnetic TM25G
Schneider Electric

NSX100 Trip Unit 3P 3D 25A Thermal-Magnetic TM25G

Ideal part number SCHC103MG025 Manufacturer number C103MG025 Barcode 3606482000490
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100 Trip Unit, 3 poles 3D 25A Thermal-Magnetic TM25G

This TM25G is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100 circuit breakers. This 25A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
25 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
17.5…25 A
