NSX100/160 Trip Unit 3P 100A Thermal-Magnetic TM100G
Schneider Electric

NSX100/160 Trip Unit 3P 100A Thermal-Magnetic TM100G

Ideal part number SCHC103MG100 Manufacturer number C103MG100 Barcode 3606482000537
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100/160 Trip Unit, 3 poles 100A Thermal-Magnetic TM100G

This TM100G is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
100 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
70…100 A
