NSX TM40D Trip Unit 3P 40A Thermal-Magnetic
Schneider Electric

NSX TM40D Trip Unit 3P 40A Thermal-Magnetic

Ideal part number SCHC103TM040 Manufacturer number C103TM040 Barcode 3606481999528
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX TM40D Trip Unit, 3 poles, 40A, Thermal-Magnetic

This TM40D is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100/160 circuit breakers. This 40A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
40 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
28…40 A
