NSX TM100DC Trip Unit 3P 100A Thermal-Magnetic

NSX TM100DC Trip Unit 3P 100A Thermal-Magnetic

by Schneider Electric

Product Details

NSX TM100DC Trip Unit, 3 poles 100A Thermal-Magnetic

TM100D/DC is a 3 poles thermal-magnetic trip unit used on ComPacT NSX 100DC circuit breakers. This 100A rating thermal-magnetic trip unit is an optimal choice for DC distribution systems. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits.
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Rated permanent current Iu
100 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
70..100 A
