NSX100/160 Trip Unit 4P 4D 40A Thermal-Magnetic TM40G
Schneider Electric

NSX100/160 Trip Unit 4P 4D 40A Thermal-Magnetic TM40G

Ideal part number SCHC104MG040 Manufacturer number C104MG040 Barcode 3606482000698
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100/160 Trip Unit, 4 poles 4D 40A Thermal-Magnetic TM40G

This TM40G is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160 circuit breakers. This 40A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
40 A
Number of poles
4
Short-circuit release function
Undelayed
Overload release current setting
28…40 A
