NSX100/160 Trip Unit 4P 4D 80A Thermal-Magnetic TM80G
Schneider Electric

NSX100/160 Trip Unit 4P 4D 80A Thermal-Magnetic TM80G

Ideal part number SCHC104MG080 Manufacturer number C104MG080 Barcode 3606482000711
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX100/160 Trip Unit, 4 poles 4D 80A Thermal-Magnetic TM80G

This TM80G is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 80A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
80 A
Number of poles
4
Short-circuit release function
Undelayed
Overload release current setting
56…80 A
