NSX TM50D Trip Unit 4P 4D 50A Thermal-Magnetic
Schneider Electric

NSX TM50D Trip Unit 4P 4D 50A Thermal-Magnetic

Ideal part number SCHC104TM050 Manufacturer number C104TM050 Barcode 3606482000216
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX TM50D Trip Unit, 4 poles 4D, 50A, Thermal-Magnetic

This TM50D is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160 circuit breakers. This 50A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
50 A
Number of poles
4
Short-circuit release function
Undelayed
Overload release current setting
35…50 A
