NSX TM63D Trip Unit 4P 4D 63A Thermal-Magnetic
Schneider Electric

NSX TM63D Trip Unit 4P 4D 63A Thermal-Magnetic

Ideal part number SCHC104TM063 Manufacturer number C104TM063 Barcode 3606482000223
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX TM63D Trip Unit, 4 poles 4D, 63A, Thermal-Magnetic

This TM63D is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 63A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
63 A
Number of poles
4
Short-circuit release function
Undelayed
Overload release current setting
44.1…63 A
