NSX TM16D Trip Unit 4P 3D 16A Thermal-Magnetic
Schneider Electric

NSX TM16D Trip Unit 4P 3D 16A Thermal-Magnetic

Ideal part number SCHC106TM016 Manufacturer number C106TM016 Barcode 3606481999924
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX TM16D Trip Unit, 4 poles 3D, 16A, Thermal-Magnetic

This TM16D is a 4 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100 circuit breakers. This 16A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Technical specifications

Rated permanent current Iu
16 A
Number of poles
4
Short-circuit release function
Undelayed
Overload release current setting
11.2…16 A
