NSX160 Trip Unit 3P 125A Thermal-Magnetic TM125DC
Schneider Electric

NSX160 Trip Unit 3P 125A Thermal-Magnetic TM125DC

Ideal part number SCHC163TM125D Manufacturer number C163TM125D Barcode 3606481994899
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX160 Trip Unit, 3 poles 125A Thermal-Magnetic TM125DC

TM125DC is a 3 poles thermal-magnetic trip unit used on ComPacT NSX 125DC circuit breakers. This 125A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. The rated current is 125A and the operational voltage is 750VDC. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Technical specifications

Rated permanent current Iu
125 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
87.5…125 A
