NSX160 Trip Unit 3P Thermal Magnetic 160A TM160DC
Schneider Electric

NSX160 Trip Unit 3P Thermal Magnetic 160A TM160DC

Ideal part number SCHC163TM160D Manufacturer number C163TM160D Barcode 3606481994905
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

NSX160 Trip Unit, 3 poles Thermal Magnetic 160A, TM160DC

TM160DC is a 3 poles thermal-magnetic trip unit used on ComPacT NSX 160DC circuit breakers. This 160A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. The rated current is 160A and the operational voltage is 750VDC. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Technical specifications

Rated permanent current Iu
160 A
Number of poles
3
Short-circuit release function
Undelayed
Overload release current setting
112..160 A
