MX Voltage Release 220-240VAC 50Hz 208-277VAC 60Hz TeSys GV4
Schneider Electric

MX Voltage Release 220-240VAC 50Hz 208-277VAC 60Hz TeSys GV4

Ideal part number SCHGV4AS287 Manufacturer number GV4AS287 Barcode 3606485444918
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

MX voltage release 220...240 V AC 50Hz 208…277 V AC 60Hz for TeSys GV4

TeSys GV electrical trip unit, MX shunt trip, 208-240V AC 50Hz/60Hz, for motor circuit breakers GV4. It trips the circuit breaker when the control voltage is applied in limits 0.7-1.1 Uc with an impulse duration greater than 20ms or a maintained signal. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

Technical specifications

Suitable for off-load switch
no
Suitable for overload relay
no
Type of electric connection
Spring clamp connection
Rated control supply voltage AC 50 Hz
220 V
Rated control supply voltage AC 60 Hz
208 V
Suitable for motor safety switch
no
Suitable for power circuit breaker
yes
Voltage type for actuating
AC
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
