MX Voltage Release 380-415VAC 50Hz 440-480VAC 60Hz TeSys GV4
Schneider Electric

MX Voltage Release 380-415VAC 50Hz 440-480VAC 60Hz TeSys GV4

Ideal part number SCHGV4AS487 Manufacturer number GV4AS487 Barcode 3606485444925
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

MX voltage release 380...415V AC 50Hz 440...480V AC 60Hz for TeSys GV4

TeSys GV electrical trip unit, MX shunt trip, 380-415V AC 50Hz / 440-480V AC 60Hz, for motor circuit breakers GV4. It trips the circuit breaker when the control voltage is applied in limits 0.7-1.1 Uc with an impulse duration greater than 20ms or a maintained signal. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

Technical specifications

Suitable for off-load switch
no
Suitable for overload relay
no
Type of electric connection
Spring clamp connection
Rated control supply voltage AC 50 Hz
380 V
Rated control supply voltage AC 60 Hz
440 V
Suitable for motor safety switch
no
Suitable for power circuit breaker
yes
Voltage type for actuating
AC
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
