MN U/voltage Release 220-240VAC 50Hz 208-240VAC 60Hz GV4
Schneider Electric

MN U/voltage Release 220-240VAC 50Hz 208-240VAC 60Hz GV4

Ideal part number SCHGV4AU247 Manufacturer number GV4AU247 Barcode 3606485444840
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

MN undervoltage release 220...240V AC 50Hz 208…240V AC 60Hz for TeSys GV4

TeSys GV electrical trip unit, MN undervoltage release, 208-240V AC 50/60Hz, for motor circuit breakers GV4. Opening of the the circuit breaker is ensured when the control voltage drops below 0.35 Uc, and possible between 0.35-0.7 Uc. Closing of the circuit breaker is possible when the control voltage is in limits 0.85-1.1 Uc. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA), Green Premium compliant (RoHS/REACh).

Technical specifications

Delayed
no
Suitable for off-load switch
no
Suitable for overload relay
no
Type of electric connection
Spring clamp connection
Rated control supply voltage AC 50 Hz
220 V
Rated control supply voltage AC 60 Hz
208 V
Suitable for motor safety switch
no
Suitable for power circuit breaker
yes
Voltage type for actuating
AC
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
