TeSys Deca Star Delta Starter 3 x 3P (3 NO) 18A 24V AC Coil
Schneider Electric

TeSys Deca Star Delta Starter 3 x 3P (3 NO) 18A 24V AC Coil

Ideal part number SCHLC3D180AB7 Manufacturer number LC3D180AB7 Barcode 3389110549225
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

TeSys Deca star delta starter 3 x 3P (3 NO) 18 A 24 V AC coil

TeSys D pre-assembled star-delta starter, for motor control applications up to 11kW@400V in delta connection. Plate mounted starter, open version, composed of 3 contactors LC1D with 24V 50/60Hz AC coils, 1NC built-in auxiliary contact on star, a time-delay contact block 1-30 sec. For operating rates until 30 starts/hour, maximum starting time 30 sec. Compact assembly (144mm width), screw fixing. Equipped with pre-wired star delta power connections, and mechanical interlock, the use of a thermal overload relay (to be ordered separately) is strongly recommended. Green Premium compliant (RoHS/REACh).

Technical specifications

Function
Star-delta contactor
Rated operation power at AC-3, 400 V
18 kW
Rated operation current Ie at AC-3, 400 V
18 A
Rated control supply voltage AC 50 Hz
24 V
Rated control supply voltage AC 60 Hz
24 V
Degree of protection
IP20 (Ip: IP20)
Type of electrical connection of main circuit
Screw connection
Voltage type for actuating
AC
