Current Transfomer Split Core Size 4 1000A-0.333VAC S4
Schneider Electric

Current Transfomer Split Core Size 4 1000A-0.333VAC S4

Ideal part number SCHLVCT01004S Manufacturer number LVCT01004S Barcode 3606480299681
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Veris LV CT 1000 A 0.333 V output split Core Curret Transformer 62 mm x 201 mm

This low-voltage split-core current transformer is part of PowerLogic BCPM (Branch Circuit Power Meter). It is Ideal for retrofit applications with Schneider Electric energy meters which accept low voltage current transducer input It is rated for a 1000A circuit. 0.333 V output, size 4. Split core opening is 62 mm x 201 mm.

Technical specifications

Model
Cable rebuilding current converter
Number of primary inputs
1
With copper rail
no
Rated primary current
1000 A
Snap mounting
no
With shock protection
no
