Modular 1ph Voltage Control Relay 5A 1CO 9-15 VDC
Schneider Electric

Modular 1ph Voltage Control Relay 5A 1CO 9-15 VDC

Ideal part number SCHRM17UAS14 Manufacturer number RM17UAS14 Barcode 3389119405102
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Harmony Modular 1-phase voltage control relay 5 A 1 CO 9…15 V DC

This Harmony RM17-U control relay allows monitoring of voltage control. This modular control relay is ideal for monitoring of electrical values and voltage variation in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market slimmest form-factors with 17.5mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a selectable memory function, integral LED for indicating control status, sealable cover, with simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. Multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC.

Technical specifications

Width
17.5 mm
Height
90 mm
Depth
72 mm
With detachable clamps
no
Single-phase under voltage possible
yes
Three-phase under voltage possible
no
Single-phase over voltage possible
yes
Three-phase over voltage possible
no
Single-phase hysteresis possible
yes
Three-phase hysteresis possible
no
Contains function DC-under voltage
yes
Contains function DC-over voltage
yes
Contains function DC-voltage hysteresis
yes
Type of voltage measuring range
DC
Type of electric connection
Screw connection
Voltage measuring range 1
9 V
Voltage measuring range 2
9 V
Max. permitted delay-on energization time
0.5 s
Max. permitted off-delay time
10 s
Min. adjustable off-delay time
0.1 s
Response value voltage
9 V
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
1
