Discrete I/O Extension Module Zelio Logic 14 I/O 100-240VAC

Discrete I/O Extension Module Zelio Logic 14 I/O 100-240VAC

by Schneider Electric
Ideal Part Number SCHSR3XT141FU Manufacturer Number SR3XT141FU Barcode 3389110550160

Product Details

Discrete I/O extension module Zelio Logic 14 I/O 100...240 V AC

This Zelio Logic SR3 discrete I/O extension module smart relays uses a supply voltage of 100V-240V alternating current. It has 14 inputs / outputs contact with screw-clamp terminals. It enables simple ladder programming, adapted for non-specialists.
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Width
72 mm
Height
90 mm
Depth
59 mm
Expandable
no
Switching current
8 A
With time switch clock
no
With display
no
Suitable for safety functions
no
Number of digital inputs
8
Number of digital outputs
6
Number of analogue inputs
0
Number of analogue outputs
0
Voltage type
AC (Supply voltage: AC)
Supporting protocol for LON
no
Number of HW-interfaces industrial Ethernet
0
Number of HW-interfaces RS-232
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces RS-485
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces USB
0
Number of HW-interfaces parallel
0
Number of HW-interfaces other
0
With optical interface
no
Supporting protocol for TCP/IP
no
Supporting protocol for ASI
no
Supporting protocol for PROFIBUS
no
Supporting protocol for CAN
no
Supporting protocol for INTERBUS
no
Supporting protocol for KNX
no
Supporting protocol for MODBUS
no
Supporting protocol for Data-Highway
no
Supporting protocol for DeviceNet
no
Supporting protocol for SUCONET
no
Supporting protocol for other bus systems
no
Redundancy
no
With relay output
yes
Rail mounting possible
yes
Explosion safety category for gas
None
Explosion safety category for dust
None
Appendant operation agent
no (Ex ia: no, Ex ib: no)
Degree of protection
IP20 (Ip: IP20)
Supporting protocol for SERCOS
no
Supporting protocol for INTERBUS-Safety
no
Number of interfaces PROFINET
0
Number of HW-interfaces Wireless
0
Front built-in possible
yes
Rack-assembly possible
no
Wall mounting/direct mounting
yes
Expansion device
yes
Radio standard Bluetooth
no
Radio standard WLAN 802.11
no
Basic device
yes
IO link master
no
Performance level according to EN ISO 13849-1
None
Supporting protocol for AS-Interface Safety at Work
no
Supporting protocol for DeviceNet Safety
no
Supporting protocol for EtherNet/IP
no
Supporting protocol for Foundation Fieldbus
no
Supporting protocol for PROFINET CBA
no
Supporting protocol for PROFINET IO
no
Supporting protocol for PROFIsafe
no
Supporting protocol for SafetyBUS p
no
Supply voltage AC 50 Hz
100 V
Supply voltage AC 60 Hz
100 V
Radio standard GPRS
no
Radio standard GSM
no
Radio standard UMTS
no
SIL according to IEC 61508
None
