SSR 20A DIN Zero Volt Switch In 90-280VAC out 24-280VAC
Schneider Electric

SSR 20A DIN Zero Volt Switch In 90-280VAC out 24-280VAC

Ideal part number SCHSSM1A112P7 Manufacturer number SSM1A112P7 Barcode 3606480579509
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Harmony Solid state modular relay 12 A DIN rail mounting Zero voltage switching input 200-265 V AC output 24...280 V AC

This Harmony SSM solid state modular DIN rail single-phase relay is rated 12A, is controlled with a 200V to 265V AC input, has a rated load voltage of 24V to 280V AC with zero voltage switching, ideal for resistive loads. It also has a visual indicator showing the status of its input. Built-in heatsink for maximum performance and less spare parts to manage. It is also silent and reliable thanks to the absence of moving contacts. Its clear schematic on the side of the socket enables easier wiring and maintenance.

Technical specifications

Number of phases
1
Modular version
yes
Rated control supply voltage AC 50 Hz
200 V
Rated control supply voltage AC 60 Hz
200 V
Voltage type for actuating
AC
