SSR 30A DIN Zero Volt Switch In 92-280VDC out 48-660VAC
Schneider Electric

SSR 30A DIN Zero Volt Switch In 92-280VDC out 48-660VAC

Ideal part number SCHSSM1A36BD Manufacturer number SSM1A36BD Barcode 3606480579400
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Harmony Solid state modular relay 6 A DIN rail mounting Zero voltage switching input 4...32 V DC output 48-600 V AC

This Harmony SSM solid state modular DIN rail single-phase relay is rated 6A, is controlled with a 4V to 32V DC input, has a rated load voltage of 48V to 600V AC with zero voltage switching, ideal for resistive loads. It also has a visual indicator showing the status of its input. Built-in heatsink for maximum performance and less spare parts to manage. It is also silent and reliable thanks to the absence of moving contacts. Its clear schematic on the side of the socket enables easier wiring and maintenance.

Technical specifications

Number of phases
1
Modular version
yes
Rated control supply voltage DC
4 V
Voltage type for actuating
AC
