SSR 25A DIN Zero Volt Switch In 90-280VAC out 24-300VAC
Schneider Electric

SSR 25A DIN Zero Volt Switch In 90-280VAC out 24-300VAC

Ideal part number SCHSSP1A125BD Manufacturer number SSP1A125BD Barcode 3606485441856
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Harmony Solid state relay 25 A Panel mounting Zero voltage switching input 3-32 V DC output 24-300 V AC

This panel mount static relay accepts wiring with either bare cable, crimped cable ends, fork lugs or ring lugs Its rated current is 25 A, is controlled with a 3 to 32 V DC circuit, has a rated load voltage of 24 to 300 V AC output. It also has a test button for easy debugging, testing and commissioning It mounts on metallic panel surface, with an excellent thermal dissipation capability thanks to its factory-installed thermal pad, or on DIN rails with an accessory heatsink It has a visual indicator showing the status of its input and a alarm output enabling a quick response to unexpected events

Technical specifications

Number of phases
1
Modular version
no
Rated control supply voltage DC
3 V
Voltage type for actuating
AC
