SSR 50A Panel Zero Volt Switch In 18-36VAC out 48-530VAC
Schneider Electric

SSR 50A Panel Zero Volt Switch In 18-36VAC out 48-530VAC

Ideal part number SCHSSP3A250B7 Manufacturer number SSP3A250B7 Barcode 3606480579875
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Harmony Solid state relay 50 A Panel mounting Zero voltage switching input 18-36 V AC output 48-530 V AC

This SSP three-phase solid state relay is part of the range of solid state modular relays Harmony. It features 50A power rating and 3NO contacts. It features a control circuit voltage of 18V to 36V AC and an output voltage (load output) of 48V to 530V AC. This relay is maintenance free, fully electronic with unlimited life span. It features a control input voltage LED indicator in green. Its protection index is IP20. It weighs 240g and its dimensions are, 101.3mm wide, 79.7mm high, 35.4mm deep. It is the ideal solution for packaging, plastic molding, textile, and heating furnace applications. It can be mounted on panel fixed by screws.

Technical specifications

Number of phases
3
Modular version
no
Rated control supply voltage AC 50 Hz
18 V
Rated control supply voltage AC 60 Hz
18 V
Voltage type for actuating
AC
