XB4 Pilot Light Sub Assembly LED White 12V AC/DC
Schneider Electric

XB4 Pilot Light Sub Assembly LED White 12V AC/DC

Ideal part number SCHZB4BVJ1 Manufacturer number ZB4BVJ1 Barcode 3389110069761
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Complete body/light block assembly, Harmony XB4, metal, universal LED, screw clamp terminals, 12V AC DC

This Harmony XB4, light block with body/fixing collar is white, operates with a universal LED. It has a metal body and is compatible with Harmony XB4 pilot lights. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push button or selector switch units via clip together assembly. It enables visual distinction of signaling units via illumination by universal LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. It is designed to fit with a standard 22mm control and signaling units, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 55°C allows versatility in usage of product.

Technical specifications

Lamp holder
Other
Transformer integrated
no
With integrated voltage decreasing resistor
no
With integrated diode
yes
Colour light source
White
Lamp type
LED
Type of fastening
Front fastening
With light source
yes
Connection type auxiliary circuit
Screw connection
Rated voltage Ue at AC 50 Hz
12 V
Rated voltage Ue at AC 60 Hz
12 V
Rated voltage Ue at DC
12 V
Voltage type for actuating
AC/DC
