XB4/5 Pbutton Head Trpl 22mm 2 x Flush No Cap 1 x Red STOP

Product Details

Head for triple headed push button Harmony XB5 XB4 flush/red projecting/flush pushbutton Ø22 mm without cap

This 3-function head provides 1 red button interface and 2 buttons without cap to your machines. It is easily installed into a standard 22mm diameter cut-out. It is also easily assembled with a collar and contact blocks to fulfill a large variety of functions. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 and IP69K. It makes it ideal for operation in harsh environments.
Request a quote for this product

Enter details to request a quote

Technical Documents

Technical Specifications

Hole diameter
22 mm
Colour button
Without button plate
Suitable for illumination
no
Number of command positions
3
Spring-return
yes
Labelled
no
Type of button
High
Colour front ring
Black
Degree of protection
Other (Ip, front side: Other)
Material front ring
Plastic
With front ring
yes
Construction type lens
Rectangular
Switching function latching
no
